Results:

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	Type	Voltage-Primary	Voltage-Secondary(FullLoad)	Current-Output(Max)	PrimaryWinding(s)	SecondaryWinding(s)	CenterTap	Power-Max	MountingType	TerminationStyle	Size/Dimension	Height-Seated(Max)	Voltage-Isolation
HSS14F1.5BS PWR XFMR LAMINATED 1500VA CHAS SolaHD	3,070	0.00	RFQ		Bulk	-	Active	Laminated Core	-	-	13.6A	Dual, Multiple Taps	Dual	No	1500VA	Chassis Mount	Solder, Quick Connect	-	-	-
HS14F2CS-CE PWR XFMR LAMINATED 2000VA CHAS SolaHD	2,258	977.99	RFQ		Bulk	-	Active	Laminated Core	-	-	18.2A	Dual, Multiple Taps	Dual	No	2000VA	Chassis Mount	Solder, Quick Connect	-	-	-
HSP5F3AS XFORMER 3KVA 240X480-120/240 SolaHD	2,079	992.78	RFQ	Datasheet	Bulk	HS5	Active	-	240V, 480V	120V, 240V	12.5A, 25A	Dual, Multiple Taps	Dual	No	3000VA	Chassis Mount	Solder, Quick Connect	254.00mm L x 177.80mm W	304.80mm	-
HZ2000A PWR XFMR LAMINATED 2000VA CHAS SolaHD	3,621	1008.74	RFQ	Datasheet	Bulk	HSZ	Active	Laminated Core	-	-	-	Dual, Multiple Taps	Single, Multiple Taps	No	2000VA	Chassis Mount	Solder, Quick Connect	-	-	-
HZ2000R PWR XFMR LAMINATED 2000VA CHAS SolaHD	3,870	1008.74	RFQ	Datasheet	Bulk	HSZ	Active	Laminated Core	-	-	-	Single	Single	No	2000VA	Chassis Mount	Solder, Quick Connect	-	-	-
HSP12F2AS XFORMER 2KVA 120//277-120/240 SolaHD	2,485	1016.01	RFQ	Datasheet	Bulk	HS1	Active	-	120V, 208V, 240V, 277V	120V, 240V	8.33A, 16.7A	Dual, Multiple Taps	Dual	No	2000VA	Chassis Mount	Solder, Quick Connect	254.00mm L x 177.80mm W	304.80mm	-
HSP10F3AS XFORMER 3KVA 600-120/240 SolaHD	2,816	1025.35	RFQ	Datasheet	Bulk	HS1	Active	-	600V	120V, 240V	12.5A, 25A	Dual, Multiple Taps	Dual	No	3000VA	Chassis Mount	Solder, Quick Connect	254.00mm L x 177.80mm W	304.80mm	-
MT1500N CONTROL TRANSFORMER,1500VA,240/4 Siemens	2,626	913.41	RFQ	Datasheet	Box	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-
HZ2000 PWR XFMR LAMINATED 2000VA CHAS SolaHD	2,682	1034.32	RFQ	Datasheet	Bulk	HSZ	Active	Laminated Core	-	-	-	Dual	Single	No	2000VA	Chassis Mount	Solder, Quick Connect	-	-	-
HS12F5AS PWR XFMR LAMINATED 5000VA CHAS SolaHD	3,532	1043.07	RFQ	Datasheet	Bulk	-	Active	Laminated Core	-	120V, 240V	41.6A	Dual, Multiple Taps	Dual	No	5000VA	Chassis Mount	Solder, Quick Connect	-	-	-
T5000 PWR XFMR LAMINATED 5000VA CHAS SolaHD	3,615	1043.34	RFQ	Datasheet	Bulk	SMT	Active	Laminated Core	-	-	-	Dual	Single	No	5000VA	Chassis Mount	Solder, Quick Connect	-	-	-
MTG0750J CONTROL TRANSFORMER,750VA,200/22 Siemens	3,477	925.71	RFQ	Datasheet	Box	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-
HSS14F2BS PWR XFMR LAMINATED 2000VA CHAS SolaHD	2,543	0.00	RFQ	Datasheet	Bulk	-	Active	Laminated Core	-	-	18.2A	Dual, Multiple Taps	Dual	No	2000VA	Chassis Mount	Solder, Quick Connect	-	-	-
HZ121500A PWR XFMR LAMINATED 1500VA CHAS SolaHD	2,281	1058.39	RFQ		Bulk	HSZ	Active	Laminated Core	-	-	-	Dual, Multiple Taps	Single, Multiple Taps	No	1500VA	Chassis Mount	Solder, Quick Connect	-	-	-
HZ121500R PWR XFMR LAMINATED 1500VA CHAS SolaHD	3,777	1058.39	RFQ		Bulk	HSZ	Active	Laminated Core	-	-	-	Single	Single	No	1500VA	Chassis Mount	Solder, Quick Connect	-	-	-
HSS14F1.5CS-CE PWR XFMR LAMINATED 1500VA CHAS SolaHD	2,043	0.00	RFQ		Bulk	-	Active	Laminated Core	-	-	13.6A	Dual, Multiple Taps	Dual	No	1500VA	Chassis Mount	Solder, Quick Connect	-	-	-
HZ121500 PWR XFMR LAMINATED 1500VA CHAS SolaHD	2,884	1087.01	RFQ	Datasheet	Bulk	HSZ	Active	Laminated Core	-	-	-	Dual	Single	No	1500VA	Chassis Mount	Solder, Quick Connect	-	-	-
HS5F10AS PWR XFMR LAMINATED 10000VA CHAS SolaHD	2,289	1110.44	RFQ	Datasheet	Bulk	-	Active	Laminated Core	240V, 480V	120V, 240V	83.3A	Dual, Multiple Taps	Dual	No	10000VA	Chassis Mount	Solder, Quick Connect	-	-	-
MT3000A CONTROL TRANSFORMER,3000VA,240/4 Siemens	2,793	1005.67	RFQ		Box	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-
MT2000I CONTROL TRANSFORMER,2000VA,380/4 Siemens	3,100	1024.12	RFQ	Datasheet	Box	*	Active	-	-	-	-	-	-	-	-	-	-	-	-	-
